model

B-type

B-GP type

B-S type

B-Y type

Check the size of the workpiece

φ27-76mm

60-80m

φ27-89mm

3.5 x 12m(Standardtype)

Customization can also be made according to needs

φ27-89mm

φ27-89mm

machine overall size

(LxWxH mm)

2000x1800x2000

6000x2200x2800

12m roller tracks on both sides

Customization can also be made according to needs

Or use existing concrete protective chambers

In the laboratory

On site movement

Ray energy

160/225/320kV

225/320kV

Optional portable device

160/200kV

Plate size

18x450px

18x450px

18x450px

18x450px

sensitivity

1-1.5%

1-1.5%

1-1.5%

1-1.5%

resolving power

>4.0lp/mm

>4.0lp/mm

>4.0lp/mm

>4.0lp/mm

Dual wire image quality meter

D10

D10

D10

D10

Transparent single wall thickness

160kV：3-6mm

225kV：3-10mm

320kV：3-15mm

Overall weight

5t

225 Testing Room:18t

320 Testing Room:25t

2t

1t

Whole machine power

<3kW

<10kW

<5kW

<3kW

Leakage dose

<2.5μSv/h

<2.5μSv/h

Welding seam inspection angle

360°

-30°~+30°

-30°~+30°

-30°~+30°

Angle between ray path and tube

Vertical translucency

-20°~+20°

Vertical translucency

-20°~+20°

Vertical translucency

-20°~+20°

Vertical translucency

-20°~+20°
